21.5" FHD LCD Panel up to 1920 x 1080 ResolutionProjected Capaci?ve Touch TechnologySupports 1 x HDMI and 1 x VGATouch Interface: 1 x USB0oC to 60oC Operating Temperature12V DC Power Input with Terminal BlockPanel and VESA MountingCharakteristik
21.5" FHD LCD Panel up to 1920 x 1080 ResolutionProjected Capaci?ve Touch TechnologySupports 1 x HDMI and 1 x VGATouch Interface: 1 x USB0oC to 60oC Operating Temperature12V DC Power Input with Terminal BlockPanel and VESA MountingAnwendungen
Industrial HMI SolutionFactory AutomationPoint-of-sale (POS) / Point-of-interest (POI)ATM / Self-service / Kiosk Application|
Model |
TPM-3221PW-A4 |
|
|
Display |
Panel Size |
21.5” |
|
Panel Type |
LCD Panel |
|
|
Aspect Ratio |
16:9 |
|
|
TPM |
1920 x 1080 (FHD) |
|
|
Viewing Angle |
178(H) x 178(V) |
|
|
Brightness |
300cd/m2 |
|
|
Contrast Ratio |
5000:1 |
|
|
Color Support |
16.7M |
|
|
Touchscreen |
Touchscreen Type |
Projected Capacitive (PCAP) |
|
Surface Hardness |
7Mohs |
|
|
Transparency |
90% (±3%) |
|
|
I/O Interface |
Video Interface |
1 x HDMI and 1 x VGA |
|
Touch Interface |
1 x USB |
|
|
OSD Control |
Function Key |
Touch Monitor On/Off, Auto, Menu, Up and Down, Multi-language OSD |
|
Menu |
Brightness, Contrast, Color Adjust, Color Temp, Auto Color, Language |
|
|
Power |
Power Supply Voltage |
12V DC Input |
|
Power Connector Type |
1 x 2-pin Terminal Block Connector |
|
|
Power Adapter |
1 x Optional AC/DC 12V/5A, 60W Power Adapter |
|
|
Environment |
Operating Temperature |
0°C to 60°C |
|
Storage Temperature |
-20°C to 70°C |
|
|
Humidity |
10%~80% (non-condensing) |
|
|
Vibration |
1.5Grms, 5-500Hz, 3Axis |
|
|
Shock |
20Grms, Half-sine 11ms |
|
|
General |
Certification |
CE / FCC |
|
Ingress Protection |
IP 54 Compliant Front Panel |
|
|
Material |
Front Panel Construction: Die-cast Flat Surface |
|
|
Mounting |
Panel Mounting / VESA Mounting (100 x 100mm) |
|
|
Dimensions (W x H x D) |
519.2 x 331 x 41.2mm |
|
|
Net Weight |
4.45kg |
|
Ordering Information
| Part No. | Description |
| TPM-3221PW-A4 | 21.5" 16:9 FHD (1920x1080), 300nits, PCAP Touchscreen |
Packing List
| Description | |
| 1 x TPM-3221PW-A4 | |
| 1 x USB Cable | |
| 1 x VGA Cable | |
| 6 x Panel Mounting Screws | |
Optional Items
Part No. Description
EA-PS-60W12VTB2xx-0111
Adapter AC/DC 12V 5A 60W
with 2-pin Terminal Block Plug 5.0mm Pitch
ACS-PS-US
Power Cable 3-pin, 180 cm,
USA Type
ACS-PS-EU
Power Cable 3-pin, 180 cm,
Euro Type
ACS-PS-CN
Power Cable 3-pin, 180 cm,
China Type
ACS-100-STD
VESA Table Stand
